Product Overview
| Model | MX75AT7R |
| Type | Reach-in chiller/freezer |
| Trays | 15 x 1/1 GN |
| Bakery trays | Fits 600 x 400mm |
| Tray clearance | 70mm |
| Chill | 75kg per cycle |
| Freeze | 35kg per cycle |
| Controls | 7 inch touch screen |
| Probe | 3 point core |
| Programs | 40 |
| Door | Right hinge |
| Refrigerant | R455A |
| Power | 20A 400V 3 phase |
| Rating | 4.0kW |
| Weight | 185kg |
| Width | 770mm |
| Depth | 790mm |
| Height | 1925mm |
| Feet | 150 to 180mm |
| Made by | Friginox |
| Made in | France |
| Warranty | 2 years on site |
Specifications from the Moffat Australia Friginox price list.
The Friginox MX75AT7R is a 15 tray reach-in blast chiller and freezer that chills 75kg or freezes 35kg per cycle. It holds 15 x 1/1 GN trays, runs off a 7 inch touch screen with a 3 point core probe and 40 programmable cycles, and needs a 20A 400V three phase supply. Made by Friginox in France, distributed and serviced in Australia by Moffat.
Best for: High volume kitchens and caterers that need 15 trays and more chilling and freezing capacity, with three phase power on site.
MX75AT7R overview
Same 15 tray, 1925mm cabinet as the MX55AT7R, but on a three phase supply with 75kg chill and 35kg freeze per cycle. If you need more trays, the MX85AT7R takes 21.
How the MX75AT7R chills
The air cooled condensing unit drives a double air flow evaporator across the trays. Pick hard or soft chill, or hard or soft freeze, and run it on the 3 point core probe or on the timer. There is also a self adaptive intelligent chilling mode. A pre-chill key gets the cabinet cold before you load, and at the end of every cycle it drops into hold mode on its own.
The fans stop as soon as the door opens, and the cabinet has 60mm of foam insulation. It runs on R455A refrigerant.
Which Friginox blast chiller do I need?
They all run on R455A and take 1/1 GN trays. The difference is tray count, chilling capacity, controls and power.
| Model | MX55AT7R | MX75AT7R | MX85AT7R |
| Trays | 15 x 1/1 GN | 15 x 1/1 GN | 21 x 1/1 GN |
| Chill | 55kg | 75kg | 85kg |
| Freeze | 20kg | 35kg | 40kg |
| Controls | Touch screen | Touch screen | Touch screen |
| Core probe | 3 point | 3 point | 3 point |
| Power | 15A 240V | 20A 400V 3 phase | 20A 400V 3 phase |
| Width | 770mm | 770mm | 770mm |
| Height | 1925mm | 1925mm | 2235mm |
| Depth | 790mm | 790mm | 790mm |
| Weight | 160kg | 185kg | 225kg |
Simple to use
The 7 inch touch screen has large keys that make it easy to use. Save up to 40 programs, and the favourites key gives shortcuts to the last 9 used. Extra functions cover ice cream hardening, ventilated drying, multiple timers with customisable phases and raw fish sanitation. Defrost is manual with automatic time control.
Options
Friginox offers a USB connection, a UV sterilisation lamp that switches off with the door open, thawing and defrosting with the door closed and a variable speed drive on the evaporator fan. These are factory options, so just let us know which you want when you order.
Warranty and support
2 years on site parts and labour by Moffat Australia nationwide. See our warranty page for the details.
Frequently asked questions
Who makes the Friginox MX75AT7R?
Friginox makes it in France. Moffat distributes it in Australia and looks after warranty and service.
What is the difference between the MX75AT7R and the MX55AT7R?
The MX55AT7R is the same 15 tray cabinet, 1925mm high. It chills 55kg and freezes 20kg per cycle on 15A 240V. The MX75AT7R chills 75kg and freezes 35kg on 20A 400V three phase.
What is the difference between the MX75AT7R and the MX85AT7R?
The MX85AT7R takes 21 trays, chills 85kg and freezes 40kg per cycle and stands 2235mm high. The MX75AT7R takes 15 trays, chills 75kg and freezes 35kg.
How much can the MX75AT7R chill and freeze?
Up to 75kg chilled or 35kg frozen per cycle. Real loads vary with the food, how thick it is and the container it sits in.
What trays does it take?
15 x 1/1 GN trays on removable, adjustable runners. The runners also take 600 x 400mm bakery trays. Tray clearance is 70mm.
Does it have a core probe?
Yes, a 3 point core temperature probe. You can run each cycle on the probe or on the timer.
Can I get a left hinge door?
Yes. It comes right hinged as standard. Left hinge is available, just let us know which when you order.
What power does it need?
A three phase 400V supply rated at 20A. It draws 4.0kW. Get your electrician to check your board has three phase before you order.
What comes with the MX75AT7R?
The cabinet, 15 pairs of shelf runners and the 3 point core probe.
How much is delivery on the MX75AT7R?
Delivery is typically $120 plus GST. Use the Freight Cost Guide button on this page for the exact price to your postcode, including whether a tailgate is needed.
Do you sell scratch and dent units?
Sometimes. These are Moffat units with freight damage or ex-display, subject to availability. Ask us if one is going.
