Product Overview
The Turbofan E35D6-30 is the biggest oven in the Turbofan range, a 6 tray full size digital electric convection oven from Moffat built for bakeries and high volume production. It takes 6 x 457mm x 762mm trays with generous 105mm spacing, driven by 12kW of heating power, a 2 speed bi-directional reversing fan and steam injection. Digital controls run 30 programs with 3-stage cooking, and a programmable oven vent gives you control over chamber humidity.
Turbofan ovens are designed and manufactured by Moffat and backed by Moffat's Australia wide service and spare parts network. The E35D6-30 is the only Turbofan that requires three phase power, and as it exceeds the 8kW unhooded limit it must be installed under an exhaust hood, or use the optional VH35-30 ventless condensing hood where ducted exhaust is not possible. Bench mount it on the supplied stainless steel feet or pair it with the SK35 stainless steel stand. Six oven wire racks are supplied.
Best for: Bakeries and high volume production kitchens that need maximum tray capacity and serious baking power.
Key features
| Tray capacity | 6 x 457mm x 762mm trays |
| Also takes | 6 x 406mm x 736mm trays |
| Tray spacing | 105mm |
| Controls | Digital time and temperature |
| Modes | Manual and program modes |
| Programs | 30 programs with 3-stage cooking |
| Steam | Steam injection mode |
| Oven vent | Program and manual control |
| Fan system | 2 speed bi-directional reversing fan |
| Heating power | 12kW |
| Thermostat range | 50°C to 260°C |
| Electrical supply | 400-415V, 3P+N+E, 12.5kW, 17.5A per phase |
| Electrical options | Can run single phase at 52A |
| Connection | Hardwired |
| Water connection (optional) | Cold water 3/4" BSP male |
| Oven chamber | Vitreous enamel, one piece |
| Lighting | Dual halogen oven lamps |
| Door | Safe-Touch vented side-hinged door |
| Hinge | Standard LH hinge door |
| Door option | Door field convertible to RH |
| External width | 910mm |
| External depth | 1022mm |
| External height | 871mm (76mm feet) |
| Included | 6 oven wire racks |
| Options | Core temperature probe kit, VH35-30 ventless hood |
| Stand options | SK35 stand with tray runners under |
| Stacking | DSKE35 double stacking kit available |
| Manufacturer | Moffat |
| Made in | New Zealand |
| Warranty | 24 months parts and labour by Moffat |
SK35 stainless steel oven stand, $990.00 plus GST
The matching Turbofan SK35 stand puts the E35D6-30 at the perfect working height and adds tray storage underneath. All stainless steel welded frame with tray runners, on swivel castors with front wheel locks. Contact us to add the SK35 to your order.
Double stacking
Two E35D6-30 ovens can be stacked using the DSKE35 double stacking kit with adjustable feet, or the DSKE35C with castors, giving you 12 full size trays in one footprint. Contact us to discuss stacked configurations.
Frequently asked questions
Does the Turbofan E35D6-30 need three phase power?
Yes. The E35D6-30 is the only oven in the Turbofan range that requires a three phase connection, drawing 12.5kW total. Every other Turbofan runs on single phase. If your site does not have three phase power, look at the E32D4 or E33D5, which deliver serious capacity on single phase. Contact us to discuss your site's power setup.
Does the E35D6-30 need to be under an exhaust hood?
Yes. At 12.5kW it exceeds the 8kW limit for unhooded electric appliances in Australia. If a ducted exhaust hood is not possible at your site, the optional VH35-30 Halton ventless condensing hood mounts directly on the oven, with 3 stage filtration and self-contained condensate collection, and plugs into a standard 10A power point. Contact us for VH35-30 pricing.
What trays does the Turbofan E35D6-30 take?
It holds 6 x 457mm x 762mm trays or 6 x 406mm x 736mm trays with 105mm spacing between shelves. Six oven wire racks are supplied.
Does the E35D6-30 have steam injection?
Yes. The E35D6-30 has a steam injection mode for crusty bread, pastry and regeneration, plus a programmable oven vent to release moisture when you want a dry bake. Connect it to a cold water supply via the optional 3/4" BSP male water connection.
What is the difference between the E32D4 and E35D6-30?
The E32D4 takes 4 full size sheet pans on single phase power in a 735mm cabinet. The E35D6-30 steps up to 6 larger trays, 12kW of heating power and 30 programs, but needs three phase power and an exhaust hood. If you are baking at production volume, the E35D6-30 is the one.
Can the E35D6-30 be stacked?
Yes. Two E35D6-30 ovens stack using the DSKE35 kit with adjustable feet or DSKE35C with castors, or the E35D6-30 can sit over a matching P Series prover.
Turbofan 30 series compared
| Model | Trays | Controls | kW | Price |
|---|---|---|---|---|
| E30M3 | 3 x GN | Mech | 2.3 | $3,450 |
| E31D4 | 4 x GN | Digital | 3.1 | $3,790 |
| E33D5 | 5 x GN | Digital | 6 | $5,390 |
| E32D4 | 4 x Full | Digital | 6.5 | $5,990 |
| G32D4 | 4 x Full | Digital | 10 | $6,790 |
| E35D6 | 6 x Full | Digital | 12.5 | $11,820 |
All prices exclude GST.
Complete the baking station
The E35D6-30 is designed to sit over a Turbofan P85 series prover, giving you prove and bake in one 910mm wide production station on castors. Match tray count to your daily output.
| P85M8 Prover and Holding Cabinet | 8 x 406x736 trays | Prove and hold | $5,350 |
| P85M12 Prover and Holding Cabinet | 12 x 406x736 trays | Prove and hold | $5,850 |
All prices exclude GST. Contact us to order the oven and cabinet together.
What warranty comes with the Turbofan E35D6-30?
24 months parts and labour, backed by Moffat's Australia wide service network.
Warranty and support
- 24 months parts and labour warranty by Moffat
- Moffat national service and spare parts network
