Scotsman ACM 47 AS Medium Gourmet Cube Ice Machine

Specifications from the Moffat Australia ACM 47 AS spec sheet.

The Scotsman ACM 47 AS is a self contained undercounter ice maker that makes up to 25kg of clear medium gourmet cubes a day at 21°C, or 21kg at 32°C, into a 9kg built in bin. It plugs into a standard 10A power point, drains by gravity and sells for $2,140 ex GST. Scotsman ice makers are distributed and serviced in Australia by Moffat, with a 3 year parts and labour warranty.

Best for: cafes, small bars, restaurants and clubs that want clear gourmet cubes for drinks and use around 20 to 25kg of ice a day.

ACM 47 AS overview

The ACM 47 AS is the entry point to the Scotsman gourmet range. At 386mm wide and 645mm high it slides under a standard bench. The ECM 47 AS OX is the same size and cube with XSafe sanitation and a pump out drain added, for $250 more.

If you need more ice, the ACS 87 AS makes up to 39kg a day of small gourmet cubes and the ACM 107 AS makes up to 51kg a day of the same medium cube. Both are 531mm wide.

How the ACM 47 AS makes ice

The ACM 47 AS uses Scotsman's horizontal evaporator spray system. Water sprays up into cups on the underside of the evaporator and freezes in layers. Minerals and air stay in the water that doesn't freeze, so the cubes come out clear and hard and melt slowly in a drink.

Each cube is a 20g gourmet cube, 30mm across and 34mm high. Agion Technology in the machine resists the growth of microbes and the development of odours.

Which gourmet ice maker do I need?

All four are self contained Scotsman gourmet ice makers with a built in bin, 10A plug in and 3 year Moffat warranty. The difference is cube size, output and footprint.

Simple to run

The ACM 47 AS runs on simple electromechanical controls, so there is very little to go wrong. A light on the front panel comes on if the machine is due for routine maintenance. The condenser air filter pulls out from the front for washing, so the machine stays where it is. The disappearing bin door opens out of the way and closes softly on a damper.

Warranty and support

3 year parts and labour warranty, backed by Moffat Australia with on site service Australia wide. It covers faults in parts and workmanship under normal commercial use. Routine cleaning, descaling and filter maintenance aren't covered. See all Scotsman ice makers or read our warranty page.

Frequently asked questions

What is the difference between the ACM 47 AS and the ECM 47 AS OX?
Same cabinet, same 20g medium gourmet cube and same 9kg bin. The ECM 47 AS OX adds the XSafe natural sanitation system and Progressive Water Discharge, a pump out drain that moves water up to 15 metres, so it doesn't need a drain lower than the machine. The ACM 47 AS makes a little more ice, 25kg a day at 21°C against 24kg, and 21kg at 32°C against 18kg. It is also $250 cheaper.

How much ice does the ACM 47 AS make?
Up to 25kg a day at 21°C air with 10°C water, and 21kg a day at 32°C air with 21°C water. Use the 32°C figure if your kitchen runs hot in summer. The 9kg bin refills as you use it.

Will the ACM 47 AS fit under my bench?
At 645mm high, 386mm wide and 600mm deep it fits under a standard 900mm bench. Leave 150mm clear at the back and both sides so the machine can breathe. It runs in air temperatures from 10°C to 43°C.

Do I need a plumber or electrician to install the ACM 47 AS?
No. It plugs into a standard 10A power point and connects to a cold water tap with the supplied water hose. The supplied drain hose runs to a floor waste or drain.

What water and drain connection does the ACM 47 AS need?
A ¾ inch cold water connection with water between 5°C and 38°C at 100 to 500kPa. The drain is gravity, so the floor waste or drain has to sit lower than the machine's ¾ inch drain outlet. If you don't have a drain lower than the machine, look at the EC series, like the ECM 47 AS OX, which pump their water out.

What is the difference between medium and small gourmet cubes?
The medium gourmet cube in the ACM 47 AS is 20g, 30mm across and 34mm high. The small gourmet cube in machines like the ACS 87 AS is 8g, 21mm across and 25mm high. Medium suits spirits, cocktails and soft drinks in a standard glass. Small packs tighter into tall glasses and jugs.

How do I look after the ACM 47 AS?
Pull the condenser air filter out from the front and wash it regularly, more often in a greasy or dusty kitchen. A light on the front panel comes on if the machine is due for routine maintenance. Regular cleaning and descaling are part of normal maintenance and aren't covered by warranty.

What comes with the ACM 47 AS?
The machine comes with a removable air filter, an ice scoop, a water hose and a drain hose. Legs are an optional extra.

Do you have scratch and dent ACM 47 AS machines?
Sometimes. Moffat occasionally has units with freight damage or ex-display stock at a lower price. It comes down to availability, so ask us if you want one.
