Product Overview
| Model | RN8100G-LS |
| Type | Target Top |
| Base | Leg Stand |
| Power | Gas |
| Burner | Dual ring cast iron |
| Gas | Natural or LPG |
| Gas power | 45MJ |
| Regulator | Supplied |
| Gas inlet | R ¾″ BSP male |
| Control | Single Hi-Lo |
| Feet | Legs, adjustable |
| Width | 900mm |
| Depth | 805mm |
| Height | 915mm |
| Weight | 178kg |
| Made by | Moffat |
| Country | New Zealand |
The Waldorf RN8100G-LS is a 900mm gas target top on its own leg stand, ready to run as a standalone unit or connected into a suite with other Target Top and cooktop equipment. It runs the same 45MJ dual ring cast iron burner as the rest of the range, with a removable centre ring for stockpots and round bottomed pans. Made in New Zealand by Moffat.
The burner sits in a 50mm thick refractory brick lined box, which holds heat well and protects the burner itself. Full pilot and flame failure protection is standard, with a single knob handling both burner output and pilot ignition, dialled from low right up to full 45MJ output. Take the centre ring out and you get direct flame contact for stockpots, paella pans and other round bottomed cookware, the ring is 280mm across. Leave it in and you've got a solid 900 x 625mm cast iron cooking surface that reaches up to 500°C at the centre.
The leg stand has a framed top that connects straight onto the Target Top, with a full stainless steel shelf underneath for extra storage. It sits on 63mm stainless steel legs with adjustable feet. No tools are needed for assembly.
This model runs on either natural gas or LPG, just let us know which when you order. Like all Moffat gas equipment except fryers, a gas regulator is supplied with the RN8100G-LS, but it is not pre-fitted, your licensed gas fitter fits it as part of installation. A gas type conversion kit is included as standard, so you're covered if you ever need to switch.
Can I run this on LPG instead of natural gas?
Yes. The RN8100G-LS is available in either gas type, just let us know which when you order. A conversion kit is included as standard if you ever need to switch.
Does the gas regulator come fitted?
No. Like all Moffat gas equipment except fryers, the regulator is supplied loose, not pre-fitted. Your licensed gas fitter fits it during installation.
Does the leg stand need tools to assemble?
No. It's a quick assembly design, the framed top connects straight onto the Target Top without any tools needed.
Warranty
- 2 year warranty, Moffat Australia wide.
