Product Overview

The Waldorf CH8600ED-LS is a 600mm electric chargrill on a leg stand, built for kitchens that want chargrill flavour without a gas connection.

Model	CH8600ED-LS
Type	Electric chargrill
Elements	5 direct contact
Power	8.4kW
Cooking area	450x590mm
Max temp	400°C
Cooking well	Water filled
Control	Dial
Supply	415V 3ph
Base	Leg stand
Feet	Adjustable feet
Width	600mm
Depth	805mm
Height	915mm
Weight	68kg
Included	Drain pan
Made by	Moffat
Country	New Zealand

Five direct contact heating elements heat the 450mm x 590mm cooking area to up to 400°C, with no cooking grates required. Separate left and right heat zone controls let you run two temperatures at once, and indicator lights show which side is heating.

The cooking well fills with water to catch drippings, which improves performance, avoids fat fires and makes cleaning easier than a dry-catch design. A manual fill tap and a slide out stainless steel drain collection pan make servicing straightforward, and the elements hinge up on a safety support stay for cleaning underneath.

The CH8600ED-LS sits on a fully modular leg stand with heavy-duty 63mm diameter 1.2mm 304 stainless steel legs and adjustable feet, with a framed stand shelf underneath for extra storage. Waldorf 800 Series is made by Moffat.

Best for: kitchens without gas that still want direct contact chargrill cooking, or sites where a gas chargrill isn't an option.

Does the CH8600ED-LS need cooking grates?

No. The direct contact elements sit right under the cooking surface, so no separate grates are required.

Why does the cooking well fill with water?

The water filled well catches drippings as you cook, which stops fat fires flaring up and keeps the grill easier to clean at the end of service. It's a manual fill, and drains through the slide out collection pan.

What's the difference between the -B, -LS and -CB versions?

All three run the same 8.4kW chargrill. The -B is bench mount only, the -LS comes on a leg stand, and the -CB comes on a fully enclosed cabinet base. The leg stand is the most practical choice if you don't already have a bench to sit it on.
