Product Overview

The Turbofan EC40T710 is a factory stacked combi oven cooking station, pairing a 7 tray EC40T7 chamber on top of a 10 tray EC40T10 chamber in one unit with a single, seamless finish. Because it comes factory built rather than assembled on site with a separate stacking kit, the join between the two ovens looks cleaner and there is no field assembly required.

Each chamber runs its own touch screen controls independently, so one oven can hold at a low temperature while the other runs a full combi cycle at a completely different setting. Turbofan combi ovens are manufactured in Italy by Lainox under license to the Moffat brand, and backed by Moffat's Australia wide service and spare parts network. The EC40T710 suits kitchens that need two ovens worth of independent capacity without doubling their footprint. Because it uses steam it needs a water supply and drain connection, unlike a standard convection oven.

Best for: kitchens that need two independently controlled combi ovens running different modes at once, without the footprint of two separate units.

Tray capacity	7 x 1/1 GN (top) and 10 x 1/1 GN (bottom)
Tray spacing	70mm
Construction	Factory stacked, single seamless unit
Controls	2 independent 7 inch capacitive touch screens
Cooking modes	Convection, Steam, Combi, independent per chamber
Range	30°C to 260°C
Programs	Multiple cycles per recipe, per chamber
Automatic cooking	Picture driven preset recipes
Climate control	Autoclima management
Multilevel	Multilevel Plus
Steam control	ECOVAPOR automatic steam
Energy control	ECOSPEED automatic temperature
Core probe	Core temperature probe included
Cleaning	LCS automatic cleaning system
Connectivity	Wi-Fi and USB
HACCP	Data download available
Fan system	2 speed auto-reversing fan
Heating power	33.4kW
Electrical supply	3 phase, 33.4kW, 50A
Electrical connection	Hardwired, Type B RCD required
Water connection	2 x 3/4" BSP
Drain	2 x 40mm outlets, tundish recommended
Extraction	Hood required
Door	Double glazed door, folding internal glass
Water filter	Supplied
Oven chamber	Stainless steel
External width	777mm
External depth	744mm
External height	1892mm
Nett weight	194kg
Manufacturer	Lainox
Made in	Italy
Warranty	24 months parts and labour

Other extras available for the EC40T710 include a hand shower with fittings, an extraction hood with air cooled condenser, bakery side racks, and a combi cleaner for the automatic cleaning system. Get in touch for pricing on any of these.

What is the benefit of a factory stacked cooking station over a stacking kit?

The EC40T710 is built as one unit from the factory rather than two ovens joined on site with a separate stacking kit, so the finish between the chambers is cleaner and there is nothing to assemble at delivery.

Can the two chambers run different modes at the same time?

Yes. Each chamber has its own touch screen and controls, so the top 7 tray oven and bottom 10 tray oven can run completely different cooking modes, temperatures and programmes at once.

What is the difference between a combi oven and a convection oven?

A convection oven only cooks with dry heat, which can shrink a roast by as much as half through moisture loss. Each chamber of the EC40T710 can run pure convection, pure steam, or a combination of both, so it holds moisture in during roasting, reheating and proving as well as covering everything a standard convection oven does.

Does the EC40T710 need a water and drain connection?

Yes. It needs two cold water connections on 3/4" BSP fittings, with softened water available as an option, and two drain outlets with a tundish positioned outside the oven's footprint, one for each chamber.

Is the EC40T710 hardwired or does it plug in?

The EC40T710 is hardwired, not a plug-in unit. It draws 50A on three phase power and requires a Type B RCD, so a licensed electrician needs to check your switchboard is set up for it before installation.

Does the EC40T710 come with a hand shower?

No, a hand shower is an optional extra rather than standard. It's useful for general rinsing and wash down around the oven.

Does the EC40T710 need an exhaust hood?

Yes. Steam is released each time either chamber's door is opened during steam or combi cooking, so a hood is needed regardless of power rating. A dedicated extraction hood is available as an optional extra for this model.
