Product Overview

The Convotherm CXGBT6.10D is a gas fired maxx pro combi oven with 7 tray capacity at full 1/1 GN depth, made in Germany. Steam comes from a high-performance boiler outside the cooking chamber, and every setting runs to 5 levels for finer control over moisture, baking and fan speed. The D in the model name means it has a disappearing door, which fully opens and slides down the right hand side of the oven, clearing the doorway completely for loading in tight kitchens.

Convotherm ovens are backed by Moffat's Australia wide service and spare parts network. The gas boiler runs on natural gas or LPG, with the control electronics plugging into a standard 10A outlet rather than needing a three phase electrical connection. The 6.10D suits kitchens that already have a gas line in and want the running cost benefits of gas over electric, plus TrayView, Regenerate+ and the disappearing door where floor space is tight.

Best for: kitchens with an existing gas supply that want maxx pro's finer 5-level control and lower running costs than the electric equivalent, with a disappearing door for easier loading in a tight space.

Key features

Tray capacity	7 x GN 1/1
Tray spacing	68mm
Controls	easyTouch 10" touch display
Cooking modes	Steam, convection, combi
Steam generation	High-performance boiler
Programs	Multiple cycles per recipe
Cleaning	ConvoClean+ auto
HACCP	Data storage
Connectivity	WiFi and Ethernet LAN, USB port
Gas supply	Natural gas or LPG, R3/4 connection
Gas consumption	42MJ/hr
Electrical supply	1P+N+E, 0.6kW, 2.7A
Electrical connection	10A cordset fitted
Water connection	G3/4" BSP
Fan	5 speed settings
Drain	Tundish recommended
Lighting	LED lighting in oven cavity
Door	Triple glass, disappearing
Door hinge	Right hinged standard
Hand shower	Recoil hand shower
Feet	Adjustable, 100mm
External width	966mm
External depth	792mm
External height	786mm
Extraction	Hood required
Nett weight	146kg
Packed weight	171kg
Manufacturer	Convotherm
Made in	Germany
Warranty	24 months parts and labour by Moffat

CSK100 combi stand

Stainless steel stand suited to .10 width maxx pro models. $1,380.00 ex GST.

Stacking

The 6.10D can be stacked with another 6.10 or with a 10.10, gas appliance on gas appliance only. Contact us for pricing once you've confirmed the combination you need.

What does CXGBT6.10D mean?

CX is the maxx pro range. G is gas (E is electric). BT is the easyTouch interface (BD is easyDial). 6 is the tray count, 10 means full size GN 1/1 trays feeding in front to back. D means disappearing door.

What is a disappearing door?

The door fully opens and slides down the right hand side of the oven cabinet, clearing the doorway completely rather than swinging open in front of the unit. It's a genuine help in tight kitchens where a standard swing door would get in the way of loading trolleys or standing room.

Does the CXGBT6.10D need a hood?

Yes. Combi ovens release steam when the door opens, so an extraction hood is required regardless of the output rating. Ventilation requirements can vary by council, so check your local regulations if unsure.

Is it plug-in or hardwired?

The control electronics plug into a standard 10A outlet with the cordset fitted, no electrician needed for the power side. The gas connection itself does need a licensed gas fitter.

What's the difference between the gas and electric versions?

Same tray capacity, same 5-level control and disappearing door. The gas model needs a natural gas or LPG line rated at 42MJ/hr instead of a three phase electrical supply, and plugs into a standard 10A outlet for its control electronics rather than being hardwired. Gas typically works out cheaper to run if you've already got the supply in, electric is simpler to install if you don't.

24 months parts and labour warranty, backed by Moffat's Australia wide service network.
National 24 hour service hotline with technicians across every state.
