Product Overview

The Waldorf GP8600G-CB is a 600mm commercial gas griddle on a fully enclosed cabinet base, with a thick machined plate and thermostatic control for even, consistent flat-top cooking.

Model	GP8600G-CB
Type	Gas griddle
Burners	1 x 53MJ
Power	53MJ
Plate area	592x530mm
Control	Dial
Ignition	Piezo
Gas	Natural or LPG
Regulator	Supplied
Gas inlet	R ¾″ BSP male
Base	Cabinet
Feet	Legs, adjustable
Width	600mm
Depth	805mm
Height	915mm
Weight	133kg
Made by	Moffat
Country	New Zealand

A single 53MJ burner heats a 592mm x 530mm griddle plate 20mm thick, with a 90-300°C thermostat for consistent, even heat across the whole surface. The plate is top weld sealed with an overlapping finish front and rear, so there's no lip or trap for grease and food debris to catch in during cleaning. The burner runs on full pilot and flame failure protection with piezo ignition.

The GP8600G-CB comes on a fully enclosed cabinet base, and takes an optional GN 1/1 four position racking kit across one or two cabinet bays. Ribbed or mirror chromed plate options and joining caps are available for multi-unit runs. Waldorf 800 Series is made by Moffat in New Zealand, and comes complete with a gas type conversion kit if you ever need to switch between natural gas and LPG.

Best for: kitchens that want enclosed under-bench storage built into a wider 600mm griddle footprint, rather than an open leg stand.

What's the difference between a Grill top and a griddle?

Grill top, or most commonly called a grill plate, is the most common type of flat grill in use. It's the option on our gas stoves and cooktops, with a thinner plate around 12mm, a single burner per 300mm section, and a simple valve instead of a thermostat, so it's either on high or low. The plate's removable for cleaning, which leaves a gap front and back that caustic cleaning fluid can work into over time and corrode. Grease is caught in a shallow tray per 300mm section.

The GP8600G-CB is a griddle, a different piece of equipment entirely. The plate is much thicker at 20mm, thermostatically controlled from 90-300°C rather than just high or low, and welded in as a sealed, non-removable unit with no gap for anything to get into. Grease drains into one deep tray under the whole plate instead of several shallow ones per section.

Can I fit shelving inside the GP8600G-CB cabinet?

Yes. It takes an optional GN 1/1 four position racking kit, available across one or two cabinet bays.

Does the GP8600G range come on other bases besides cabinet?

Yes. This GP8600G-CB is the cabinet base version specifically. The GP8600G-B comes on bench legs, and the GP8600G-LS comes on an open leg stand.

What gas type does the GP8600G-CB run on?

Either natural gas or LPG, just let us know which when you order. Connection is a ¾″ BSP male gas inlet, so a licensed gas fitter makes the connection.
