Product Overview

The Convotherm CXEBT6.10D is a maxx pro combi oven with 7 tray capacity at full 1/1 GN depth, made in Germany. Steam comes from a high-performance boiler outside the cooking chamber, and every setting runs to 5 levels for finer control over moisture, baking and fan speed. The D in the model name means it has a disappearing door, which fully opens and slides down the right hand side of the oven, clearing the doorway completely for loading in tight kitchens.

Convotherm ovens are backed by Moffat's Australia wide service and spare parts network. The 6.10D suits busier kitchens that want the finer control and bigger 10" touch screen of the maxx pro range, plus TrayView, Regenerate+ and the disappearing door for easier tray access where floor space is tight.

Best for: busy kitchens that want maxx pro's finer 5-level control and boiler-generated steam, with a disappearing door for easier loading in a tight space.

Key features

Tray capacity	7 x GN 1/1
Tray spacing	68mm
Controls	easyTouch 10" touch display
Cooking modes	Steam, convection, combi
Steam generation	High-performance boiler
Programs	Multiple cycles per recipe
Cleaning	ConvoClean+ auto
HACCP	Data storage
Connectivity	WiFi and Ethernet LAN, USB port
Heating power	11.0kW
Electrical supply	3P+N+E, 11.0kW, 15.9A
Electrical connection	Hardwired
Water connection	G3/4" BSP
Fan	5 speed settings
Drain	Tundish recommended
Lighting	LED lighting in oven cavity
Door	Triple glass, disappearing
Door hinge	Right hinged standard
Hand shower	Recoil hand shower
Feet	Adjustable, 100mm
External width	966mm
External depth	792mm
External height	786mm
Extraction	Hood required
Nett weight	139kg
Packed weight	163kg
Manufacturer	Convotherm
Made in	Germany
Warranty	24 months parts and labour by Moffat

CSK100 combi stand

Stainless steel stand suited to .10 width maxx pro models. $1,380.00 ex GST.

Stacking

The 6.10D can be stacked with another 6.10 or with a 10.10, electric appliance on electric appliance only. Contact us for pricing once you've confirmed the combination you need.

What does CXEBT6.10D mean?

CX is the maxx pro range. E is electric (G is gas). BT is the easyTouch interface (BD is easyDial). 6 is the tray count, 10 means full size GN 1/1 trays feeding in front to back. D means disappearing door.

What is a disappearing door?

The door fully opens and slides down the right hand side of the oven cabinet, clearing the doorway completely rather than swinging open in front of the unit. It's a genuine help in tight kitchens where a standard swing door would get in the way of loading trolleys or standing room.

Does the CXEBT6.10D need a hood?

Yes. Combi ovens release steam when the door opens, so an extraction hood is required regardless of the kW rating. Ventilation requirements can vary by council, so check your local regulations if unsure.

Is it plug-in or hardwired?

Hardwired. The 6.10D draws 15.9A on a 400V three phase supply and needs an electrician to connect it.

What's the difference between maxx pro and the standard maxx range?

The maxx pro is made in Germany with a boiler generating steam, 5-level control over moisture, baking and fan speed, a bigger 10" touch screen, TrayView, Regenerate+ and the option of a disappearing door. If you're running high volumes and want the extra control, maxx pro is worth the step up.

24 months parts and labour warranty, backed by Moffat's Australia wide service network.
National 24 hour service hotline with technicians across every state.
