Product Overview
The Scotsman ECS 87 AS OX is a self-contained under counter gourmet ice machine producing up to 31kg of crystal clear small gourmet cubes per day at 32°C ambient. Part of the EC Series, it includes XSafe UV sanitisation which continuously sanitises ice in the bin throughout the day, and PWD progressive water discharge which pumps melt water up to 15 metres for installations where gravity drainage is not possible. Small gourmet cube — 21mm diameter, 25mm high, 8 grams each. The 19kg integrated storage bin fits under a standard counter on the included adjustable feet. Scotsman has been designing and manufacturing ice machines since the 1950s. Backed by a 3-year parts and labour warranty through Moffat.
Features
- Self-contained under counter ice machine
- Small gourmet cube, 21mm x 25mm, 8g
- Up to 31kg production per day at 32°C
- 19kg integrated storage bin
- XSafe UV natural sanitation system
- PWD progressive water discharge up to 15 metres
- Horizontal ice evaporator spray technology
- Crystal clear slow-melting gourmet cubes
- R290 refrigerant gas
- Agion antimicrobial technology
- Front access condenser air filter
- Removable and washable air filter
- Disappearing door for easy bin access
- Maintenance reminder light
- Simple electromechanical controls
- Stainless steel exterior
- Adjustable feet included
- Includes ice scoop
- Supplied with water and drain hoses
- 3-year parts and labour warranty
Specifications
| Model | ECS 87 AS OX |
| Ice type | Gourmet small cube |
| Cube size | 21mm x 25mm, 8g |
| Production at 32°C | 31kg per 24 hours |
| Production at 21°C | 39kg per 24 hours |
| Storage bin | 19kg |
| Width | 531mm |
| Depth | 600mm |
| Height | 825mm (including feet) |
| Nett weight | 46kg |
| Electrical | 230-240V, 570W, 10A |
| Connection | 10A cordset supplied |
| Refrigerant | R290 |
| Water inlet | R 3/4" |
| Water pressure | 100 to 500 kPa |
| Operating temperature | 10°C to 43°C ambient |
| Warranty | 3 years parts and labour |
Optional accessories
A water filter is recommended to protect the machine and improve ice quality. Ask us about the right filter for your installation.
