Product Overview

The Convotherm CXEBD6.10 is a 7 tray electric boiler combi oven built for kitchens that want straightforward steam, combi and convection cooking without a touch screen learning curve. It holds 7 x GN 1/1 trays on 68mm spacing and runs on a high performance boiler generating steam outside the cooking chamber for consistent saturation. The easyDial control is a single rotary dial with a digital display and a TriColor status ring, so every function sits on one operating level.

Convotherm combi ovens are manufactured in Germany and distributed in Australia by Moffat, backed by Moffat's Australia wide service and spare parts network. The CXEBD6.10 suits cafes, smaller commercial kitchens and sites where staff need to get up to speed on the oven fast. It stores 99 cooking profiles of up to 9 steps each, runs ConvoClean automatic cleaning, and has HACCP data storage built in. If you want the full easyTouch feature set with Press&Go and a disappearing door, the easyTouch range is the step up from here.

Best for: cafes and smaller commercial kitchens wanting simple, reliable steam, combi and convection cooking with a hardwired electrical connection.

Tray capacity	7 x 1/1 GN
Tray spacing	68mm
Controls	easyDial rotary dial with digital display
Cooking modes	Steam, Combi-steam, Convection
Steam generation	High performance boiler outside the cooking chamber
Programs	99 cooking profiles, up to 9 steps each
Cleaning	ConvoClean auto
HACCP	Data storage
Connectivity	Ethernet/LAN optional, not standard
Heating power	11.0kW
Electrical supply	400V, 3P+N+E, 11.0kW, 15.9A
Electrical connection	Hardwired
Water connection	G3/4" BSP
Fan	5 speed settings
Drain	Tundish recommended
Lighting	LED lighting in oven cavity
Door	Triple glass, standard hinged door
Door hinge	Right hinged standard
Hand shower	Integrated recoil hand shower
Feet	Adjustable, 100mm to 125mm
External width	875mm
External depth	792mm
External height	786mm
Extraction	Hood required
Nett weight	133kg
Packed weight	158kg
Manufacturer	Convotherm
Made in	Germany
Warranty	24 months parts and labour by Moffat

Stand

A stainless steel stand is available to suit the CXEBD6.10. Contact us for current pricing.

Stacking

A CXEBD6.10 can be stacked on another CXEBD6.10, or on a CXEBD10.10 as the base unit, electric on electric only. Stacking kit pricing is not yet published, contact us for a quote before ordering.

Does the CXEBD6.10 need an electrician to install?

Yes. The CXEBD6.10 is hardwired, draws 15.9A on a three phase 400V supply, and needs a licensed electrician for installation. It is not a plug-in appliance.

How does the steam generation work?

Steam is generated by a high performance boiler outside the cooking chamber, giving guaranteed saturation for steam mode and automatic moisture control in combi-steam mode. Natural Smart Climate (ACS+) manages humidity and airflow through the cook automatically, with Crisp&Tasty, BakePro and HumidityPro extra functions if finer control is needed.

What trays does it take?

The CXEBD6.10 takes 7 x GN 1/1 trays on 68mm spacing, or up to 5 x 600 x 400mm baking sheets with the appropriate rack fitted.

easyDial or easyTouch, what's the difference?

Both ranges run the same boiler, cooking modes and Natural Smart Climate functions. easyDial uses a single rotary dial and digital display with a TriColor status ring, stores 99 cooking profiles, and has a standard hinged door. easyTouch adds a 10 inch capacitive touch screen, Press&Go automatic cooking with up to 399 profiles, WiFi and Ethernet as standard, and a disappearing door. If your kitchen wants the simplest possible control and a lower price point, easyDial covers the same core cooking performance.

Do I need an exhaust hood?

Yes. Combi ovens release steam every time the door opens, so extraction is required regardless of the kW rating. Ventilation requirements can vary by council, so check your local regulations if unsure.

24 months parts and labour warranty, backed by Moffat's Australia wide service network.
National 24 hour service hotline with technicians across every state.
