Product Overview
The Washtech XG is a compact recirculating undercounter glasswasher built for cafes, bars and small restaurants that need reliable, efficient glass cleaning in a space-saving footprint. At just 440mm wide it fits under most bars and countertops, uses only 1.5 litres of water per cycle, and delivers clean results in 60 or 120 seconds with no commissioning required. The XG also doubles as a compact dishwasher, handling light crockery as well as glassware, making it a versatile choice for small venues that need one machine to do both jobs.
Best for: Cafes, wine bars, small restaurants and venues washing up to 540 glasses per hour or light crockery, that need a compact water-efficient machine with simple push-button operation.
How the Washtech XG cleans
The XG is a recirculating machine, meaning wash water is filtered and recirculated during the cycle rather than drained after every wash. At just 1.5 litres of hot water per cycle it is one of the most water-efficient glasswashers available in Australia, earning WaterMark certification. The final rinse sanitises at 82°C and the stainless steel wash and drain filter keeps the wash water clean throughout service. Hands-free draining with no drain plug means end-of-service cleanup is straightforward.
Key features
| Feature | Detail |
|---|---|
| Wash cycles | 60 and 120 seconds |
| Water consumption | 1.5 litres per cycle |
| Throughput | Up to 540 glasses per hour |
| Rinse temperature | 82°C (sanitising) |
| Wash heating | 2.5 kW wash / 3.0 kW rinse |
| Controls | Push-button start with PCB timing and heating control |
| Wash arms | Precision moulded jets |
| Rack size | 365 mm x 435 mm (standard bar glass rack) |
| Wash chamber height | 290 mm clearance |
| Dimensions | W 440 mm x D 515 mm x H 780 mm |
| Weight | 33 kg unpacked |
| Power | 240V / 15 amp single phase |
| Drainage | Built-in drain pump, hands-free, no drain plug required |
| Chemical pumps | Dual chemical pumps standard |
| Filtration | Stainless steel wash and drain filter |
| WaterMark certified | Yes, meets all Australian state health regulations |
| Construction | Fully welded marine-grade stainless steel |
| Made in | New Zealand |
| Warranty | 2 years parts and labour / 5 years on the cabinet |
Simple to run, easy to repair
Like the XV and XU undercounter dishwashers, the XG uses two simple PCB control boards — one for timing and one for heating. Both are universal across the full Washtech X series, meaning any technician will carry them as standard. If one ever needs replacing, parts cost under $300 each and can be swapped quickly. Push-button start means any staff member can operate the XG with zero training. Quick-connect installation with everything supplied means no commissioning is required out of the box.
Warranty and support
The Washtech XG is backed by Moffat Australia's national service network with parts stocked locally nationwide.
- 2-year comprehensive warranty on parts and labour
- 5-year warranty on the stainless steel cabinet
- Moffat national service and spare parts network
What's in the box
- Washtech XG commercial glasswasher
- 1 x 365 mm glass rack
- Service connections for power, water, pumped waste, detergent and rinse fluid
- User and maintenance guide
Frequently asked questions
What is the difference between the Washtech XG and the Washtech GM? The XG is a compact entry-level recirculating glasswasher using push-button PCB controls, 1.5 litres per cycle and 540 glasses per hour. The GM is a professional-grade machine using the same touchscreen control panel as the M2, with higher throughput of up to 1,000 glasses per hour and Hot Rinse Retention for superior wash results. The XG suits small venues wanting simplicity and efficiency. The GM suits venues needing higher volume and professional results.
What is the difference between the Washtech XG and the Washtech GE? The XG is recirculating, meaning it filters and reuses wash water, using just 1.5 litres per cycle. The GE is non-recirculating, using fresh water every cycle at 5 litres per cycle but with no wash pump and gravity drain. The XG is more water-efficient for high-volume use. The GE is simpler with fewer components to maintain.
What rack size does the Washtech XG use? The XG uses a 365 mm x 435 mm rack, the standard size for most Australian bar glass racks.
Does the Washtech XG need commissioning? No. It is quick-connect with everything supplied and ready to use out of the box.
Is the Washtech XG WaterMark certified? Yes. WaterMark certified and compliant with health regulations in all Australian states.
For a full explanation of how Washtech controls work across the range, see our Washtech controls guide.
